FIG. 01 · Eaton 9PX EBM · 48V – 240V
Eaton 9PX EBM
Battery extension modules to increase 9PX runtime, from minutes to hours of backup.
- Rating
- 48V – 240V
- Phase
- Single-phase
- Topology
- standby
- Form factor
- mixed
- Battery
- vrla
- Variants
- 5
- Plug-in extension to 9PX
- Rack/tower convertible chassis
- Hot-swappable battery cells
- Daisy-chain multiple EBMs
- Matching 2U / 3U form factor
- 5-year battery design life
Gallery
Detail
The Eaton 9PX EBM in context.
Eaton 9PX EBMs (Extended Battery Modules) plug into 9PX UPS systems to increase battery runtime. Configurations available from 48V (1-1.5kVA) through 240V (8-11kVA), in matching 2U or 3U rack/tower form factors.
UPS Services supplies and commissions EBMs as part of standard 9PX installations to deliver the runtime your application requires.
Manufacturer overview: Eaton Eaton 9PX EBM
Variants & specifications
5 models in the Eaton 9PX EBM range.
Pricing depends on accessories, runtime, network management, and service level. Quote returned within one business day for any model below.
| Model | Rating | Notes |
|---|---|---|
| 9PXEBM48RT2U | 48V | For 9PX 1kVA / 1.5kVA, 2U |
| 9PXEBM72RT2U | 72V | For 9PX 2kVA / 3kVA, 2U |
| 9PXEBM72RT3U | 72V | For 9PX 2kVA / 3kVA, 3U |
| 9PXEBM180 | 180V | For 9PX 5kVA / 6kVA |
| 9PXEBM240 | 240V | For 9PX 8kVA / 11kVA |
