FIG. 01 · Eaton 5PX Gen2 · 1500VA – 3000VA
Eaton 5PX Gen2
Premium line-interactive rack/tower UPS with energy metering. The IT department workhorse.
- Rating
- 1500VA – 3000VA
- Phase
- Single-phase
- Topology
- line-interactive
- Form factor
- mixed
- Battery
- vrla
- Variants
- 5
- Energy metering per outlet group
- Hot-swappable batteries
- Graphical LCD
- Rack/tower convertible
- 8 IEC C13 + 1 IEC C19 outlets
- Eaton Intelligent Power Manager
Gallery
Detail
The Eaton 5PX Gen2 in context.
The Eaton 5PX Gen2 is the upper-tier line-interactive UPS in the Series 5 family, 1500-3000VA in rack/tower convertible chassis with energy metering down to outlet group level, hot-swappable batteries, and graphical LCD. Strong fit for IT racks where you want metering and visibility but don't need full online double conversion.
UPS Services installs and supports the full 5PX Gen2 range across Australian sites.
Manufacturer overview: Eaton Eaton 5PX Gen2
Variants & specifications
5 models in the Eaton 5PX Gen2 range.
Pricing depends on accessories, runtime, network management, and service level. Quote returned within one business day for any model below.
| Model | Rating | Notes |
|---|---|---|
| 5PX1500IRT2UAUG2 | 1500VA / 1350W | Rack/tower 2U |
| 5PX2000IRT2UAUG2 | 2000VA / 1800W | Rack/tower 2U |
| 5PX2200IRT2UAUG2 | 2200VA / 2200W | Rack/tower 2U |
| 5PX3000IRT2UAUG2 | 3000VA / 3000W | Rack/tower 2U |
| 5PX3000IRT3UAUG2 | 3000VA / 3000W | Rack/tower 3U |
Companion systems
Products that complete a system around the Eaton 5PX Gen2.
Battery extensions, bypass panels, monitoring cards and accessories that match this series.
