FIG. 01 · Eaton Power Xpert 9395P · 250kVA – 1200kVA
Eaton Power Xpert 9395P
Megawatt-class three-phase UPS for the largest Australian data centres and industrial sites.
- Rating
- 250kVA – 1200kVA
- Phase
- Three-phase
- Topology
- modular
- Form factor
- modular
- Battery
- mixed
- Variants
- 8
- Up to 96.3% double-conversion efficiency
- Energy Saver System (ESS) up to 99%
- Hot-swappable power modules
- VRLA / Lithium-ion / Supercapacitor
- 2N or N+1 parallel configurations
- Modbus, BACnet, SNMP integration
Gallery
Detail
The Eaton Power Xpert 9395P in context.
The Eaton Power Xpert 9395P is the highest-capacity three-phase UPS in the Eaton range, 250kVA through 1200kVA, modular with 1-4 power modules per frame, supporting VRLA, lithium-ion or supercapacitor storage. Designed for hyperscale data centres, healthcare central plant, and heavy industrial applications.
UPS Services delivers manufacturer-aligned commissioning of 9395P systems including parallel and 2N redundant configurations, with battery cabinet installation to AS/NZS 5139 and load bank SAT testing.
Manufacturer overview: Eaton Eaton Power Xpert 9395P
Variants & specifications
8 models in the Eaton Power Xpert 9395P range.
Pricing depends on accessories, runtime, network management, and service level. Quote returned within one business day for any model below.
| Model | Rating | Notes |
|---|---|---|
| 9395P-250 | 250kVA | Single power module |
| 9395P-300 | 300kVA | Single power module |
| 9395P-500 | 500kVA | Modular |
| 9395P-600 | 600kVA | Modular 1-2 PMs |
| 9395P-750 | 750kVA | Modular |
| 9395P-900 | 900kVA | Modular 1-3 PMs |
| 9395P-1000 | 1000kVA | Modular |
| 9395P-1200 | 1200kVA | Modular 1-4 PMs |
Companion systems
Products that complete a system around the Eaton Power Xpert 9395P.
Battery extensions, bypass panels, monitoring cards and accessories that match this series.
Specify a Eaton Power Xpert 9395P
